ILMU-361 Digital 6-in-1 AC Multi-Function Monitor AC Voltage and Current Frequency Factor Active Power Electricity Digital Colored Screen Display

Sku: ILMU-361
$36.90 USD
Translation missing: en.products.product.shipping_policy_html
Quantity:
Add to Wishlist Remove From Wishlist
Visa Mastercard PayPal American Express Google Pay Apple Pay Shop Pay

A multi-function digital meter that measures AC voltage, AC current, active power, power factor, power frequency, and electric energy.

Features:

  • Auto saving function
  • Large digital colored display
  • Multi-Function meter



Technical Specifications

  • Measuring Range:
    • AC voltage: AC 40.0~300.0V
    • AC current: AC 0~100.0A, minimum resolution is 0.01A
    • Power frequency: 45.0Hz~65.0Hz
    • Power factor: 0.00~1.00PF
    • Active power: 0~30000W when the active power between 0 and 9999.9W, the display accuracy is 0.1W
    • Electric energy: 0~9 99999kwh,when the electric power between 0 and 999.99kwh, the display accuracy is 0.01kwh, when between 10000.0~9999.9kwh, the display accuracy is 0.1kwh，when between 10000.0 and 999999kwh, the display accuracy is 1kwh
  • Accuracy: 1%
  • Speed:2 times per second
  • Size: 79 x 43 x 48
  • Auto saving: when power is off the electric energy will be saved and the saved electric energy will be accumulated and continue when the meter is powered on again.

Set Includes:

  • 1 x Digital Multimeter
  • 1 x Standard Factory Packaging

A printed user manual is already included with this item. No digital user manual or software is available.
